Công tắc KNX Elsner eTR serie cảm ứng kính

KNX eTR 205/206 Light

Button for Temperature Control and Light

The KNX eTR 205/206 Light push button has touch-sensitive buttons with which functions can be called up in the KNX building bus system. The glass surface is printed with areas for setting the temperature and light. LEDs are integrated in these areas and their behaviour can be adjusted. A temperature sensor is integrated into KNX eTR 205/206 Light. An external temperature reading can be received via the bus and processed with its own data to create a total temperature (mixed value).

  • Operating zone for temperature control with 2 areas (warmer, cooler)
  • LEDs can be set. All LEDs Off, all LEDs as ambient lighting, all LEDs individually controllable
  • Area function when touching two or more push buttons. Can be configured as switch, selector switch, as 8 or 16 bit encoder or for scenario recall
  • Temperature measurements. Mixed value from own measured value and external values (proportion can be set by percentage), output of minimum and maximum values
  • PI-controller for heating (one or two-level) and cooling (one or twolevel) according to temperature. Regulation according to separate setpoints or basic setpoint temperature
  • 2 AND and 2 OR logic gates each with 4 inputs. 8 logic inputs (in the form of communications objects) can be used as inputs for the logic gates. The output from each gate can be configured optionally as 1-bit or 2 x 8-bit

Additional functions KNX eTR 205 Light:

  • 1 operating zone for light with 2 areas (switching/dimming with short/ long distinction)

Additional functions KNX eTR 206 Light:

  • 2 operating zones for light with 2 areas (switching/dimming with short/ long distinction)

Configuration is made using the KNX software ETS 5

Thông số kỹ thuật

Công tắc KNX cảm ứng kính với tính năng điều khiển : nhiệt độ, đèn, rèm cửa

  • Nhựa
  • Kính cảm ứng màu trắng hoặc đen
  • IP 10, Operation 0…+55°C, storage -30…+85°C
  • 5…95% RH
  • KNX bus
  • tối đa 254
  • KNX eTR 205 Light: 92
    KNX eTR 206 Light: 98
